16 way Power Divider
| Leader-mw | Introduction to 16 way power divider |
Wilkinson Power Dividers, 16 Way
Power divider and power SPLITTER looks very similar, and is the signal is divided into two road, all the way both have what different?Sometimes it's silly points not clear, in fact, their basic respectively is internal separation of power between the resistance of the structure is different.Power separator , with two 50 Ω resistance, only the input port of 50 Ω, 83.3 Ω, other port.Used in the level and ratio measurement to improve the output and the source of matching, thus minimizing the measurement uncertainty.Power DIVIDER, with three 16 2/3 Ω resistance, all ports are 50 Ω, used to separate the source signal into two equal, in order to compare measurements.Power divider is available in two output ports provide good impedance matching.Also can be used to different properties of the two lines of the output signal of measure, such as: frequency and power.Power divider can also be used for the combination of two way signal, because the port is a two-way street.
Power dividers can be used widely in systems to allow the splitting of one signal into multiple signals with equal magnitude and phase. RF ONE offers a range of resistive and Wilkinson power dividers with broad bandwidths（DC-67GHz) and narrow bandwidths. Available in output ports of 2-way, 3-way, 4-way, 6-way, 8-way,12-way,16-way and interfaces of SMA, N type, 2.92mm, 2.4mm, 1.85mm etc.
| Leader-mw | Application |
•16 way Power divider Splitter combiner allow you to use a common distributor system for all mobile communication applications in the broad frequency range.
•Divide one signal into multichannel ones, that ensures the system to share common signal source and BTS system.
•·Meet various demands of network systems with the Ultra-wideband design.
•16 way Power dividerSuitable for the indoor coverage system of cellular mobile communication
| Leader-mw | Specification |
| Part Number | Frequency Range (MHz) | Way | Insertion Loss (dB) | VSWR | Amplitude (dB) | Phase (Degree) | Isolation (dB) | DIMENSION L×W×H (mm) | Connector |
| LPD-0.1/0.22-16S | 100-220 | 16 | ≤2.0dB | ≤1.5: 1 | 0.5 | 5 | ≥20dB | 240x70x14 | SMA |
| LPD-0.8/2.5-16S | 800-2500 | 16 | ≤1.8dB | ≤1.6: 1 | 0.5 | 8 | ≥20dB | 220x80x14 | SMA |
| LPD-0.8/2-16S | 800-2000 | 16 | ≤2.2dB | ≤1.5: 1 | 0.5 | 6 | ≥18dB | 221x77x10 | SMA |
| LPD-0.8/3-16S | 800-3000 | 16 | ≤2.5dB | ≤1.60: 1 | 0.5 | 8 | ≥18dB | 223x93x14 | SMA |
| LPD-1.4/4-16N | 1400-4000 | 16 | ≤2.5dB | ≤1.80: 1 | 0.8 | 8 | ≥18dB | 374x66x10 | SMA |
| LPD-1.6/8-16S | 1600-8000 | 16 | ≤3.5dB | ≤1.60: 1 | 1 | 12 | ≥12dB | 193x78x14 | SMA |
| LPD-2/8-16S | 2000-8000 | 16 | ≤3.0dB | ≤1.50 :1 | 0.6 | 8 | ≥16dB | 220x88x10 | SMA |
| LPD-3.5/4.2-16S | 3500-4200 | 16 | ≤2.2dB | ≤1.50: 1 | 0.5 | 8 | ≥20dB | 207x51x10 | SMA |
| LPD-9.35/9.45-16S | 9350-9450 | 16 | ≤2.5dB | ≤1.60 :1 | 1 | 10 | ≥18dB | 212X55X10 | SMA |
| LPD-7/12-16S | 7000-12000 | 16 | ≤3.0dB | ≤1.80 :1 | 1 | 10 | ≥16dB | 212X60X10 | SMA |
| LPD-14/18-16S | 14000-18000 | 16 | ≤3.0B | ≤1.80:1 | 2 | 12 | ≥15dB | 212X67X10 | SMA |
| LPD-6/26-16S | 6000-26000 | 16 | ≤2.0B | ≤2.0:1 | 2 | 12 | ≥15dB | 221X70X10 | SMA |
